JD Squared Model 32 Hydraulic Bender



Made in USA

Super heavy duty version of the Model 3

Hydraulic configuration

Includes 10 ton cylinder

Die sets, pumps, hoses and stand sold separately

Improvements are as Follows:

Frame strength has been more than doubled.

7/8" diameter 100,000 psi alloy pins were upgraded to 1 1/4" diameter.

A die locking mechanism was designed that both helps bend thin wall tubing as well as very heavy walled tubing by preventing the die from relaxing when not bending. Springback is the #1 cause of wrinkling thin walled tubing.

The Model 32 has been designed for mechanical or hydraulic operation from day one. Its hydraulic swivel block rotates on the cylinders true center axis thereby eliminating side load on the ram during bending. This greatly extends the life of the cylinder. A one piece steel ram yoke with quick disconnect pin is now incorporated as well.

An anti- springback ratchet is now included free with the bender. This allowed us to design a new ratchet lever system with more than a 20% reduction in bending effort.

Geometry of the bender itself was altered to take better advantage of the new generation 3 followbars thus yielding better bends.

Drive link bolts and sleeves sizes have increased from 1/2" diameter to 3/4" to handle the extra load.
